Our misting system incorporates high pressure pump, stainless steel nozzles and misting lines or/and mist fans which water is atomised into mist that absorbs the ambience heat and reduces the temperature.

We offer quality, customized, and innovative misting systems for residential, industrial, commercial or any other outdoor events. It can also be used in various industries to control dust, odor, pollutants, etc.

  • 1000 psi operating pressure for optimal misting effect
  • Nickel-plated forged brass manifold for anti-rust and corrosion
  • Patented internal rinse cooling design to increase pumps life
  • Dual bearing design to lower the heat and noise level down to 75 dB
  • Automatic pressure valve controls the consistency of the pump pressure
  • Circuit breaker for electrical safety if the voltage is outside of the safety parameter
  • Suitable to use in trampoline, barns, greenhouse, construction sites, pool sides, patio, etc
Download Catalogue

TAT 040-BP

Pressure: 1000psi/70bar
Volume: 0.45 L/min
No. 1 Nozzle (46cc): 8 pcs
Motor: 125W
AMP: 1.13
RPM: 4p/1420
Volt: 230V/50Hz

TAT 1001/TAT 1001-BP

Pressure: 1000psi/70bar
Volume: 0.94 L/min
No. 1 Nozzle (46cc): 20 pcs
Motor: 1/4 hp
AMP: 2.25
RPM: 4p/1420
Volt: 230V/50Hz

TAT 2000/TAT 2000-BP

Pressure: 1000psi/70bar
Volume: 2.23 L/min
No. 1 Nozzle (46cc): 44 pcs
Motor: 280W
AMP: 2.5
RPM: 8p/720
Volt: 230V/50Hz

TAT 3300/TAT 3300-BP

Pressure: 1000psi/70bar
Volume: 3.62 L/min
No. 1 Nozzle (46cc): 72 pcs
Motor: 370W
AMP: 3.42
RPM: 8p/720
Volt: 230V/50Hz

TAT 4500/TAT 4500-BP

Pressure: 1000psi/70bar
Volume: 4.78 L/min
No. 1 Nozzle (46cc): 98 pcs
Motor: 1 hp
AMP: 4
RPM: 6p/920
Volt: 230V/50Hz

TAT 70

Pressure: 1000psi/70bar
Volume: 2.1-6.77 L/min
No. 1 Nozzle (46cc): 30-132 pcs
Motor: 1.5 hp
AMP: 5.5
RPM: 315-913
Volt: 230V/50Hz
